產品規格
Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6
Coverage
Large homes
Data Rate
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps
802.11ax (2.4GHz) : up to 574 Mbps
802.11ax (5GHz) : up to 1201 Mbps
Antenna
Internal dual-band antenna x 2
Transmit/Receive
MIMO technology
2.4 GHz 2 x 2
5 GHz 2 x 2
Memory
256 MB Flash
256 MB RAM
Wi-Fi Technology
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80 MHz bandwidth
Operating Frequency
2.4 GHz / 5 GHz
Encryption
WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
Management
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log
VPN Support
IPSec Pass-Through
PPTP Pass-Through
OpenVPN server
PPTP client
L2TP client
OpenVPN client
WAN Connection
TypeInternet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Utilities
Router setup wizard; Firmware restoration; Device discovery; printer setup utility
Ports
RJ45 for 1000 BaseT for WAN/LAN x 1, RJ45 for 1000 BaseT for LAN x 1
Features
Router app
MU-MIMO
Airtime Fairness
Smart Connect
Traffic Analyzer
Traditional QoS
AiProtection Classic
Parental Control
Guest Network : 9
VPN server : PPTP Server, OpenVPN Server, IPSec server
VPN client : PPTP client, L2TP client, OpenVPN client
IPTV support
OFDMA
Bandwidth Limiter
Beamforming
Button
WPS Button, Reset Button
LED Indicator
Power x 1
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1.5 A current
OS Support
Windows® 10
Windows® 8
Windows® 7
Mac OS X 10.6 or Above
iOS9.0 (Optional) or higher
AndroidTM
Dimensions
9.0 x 9.0 x 8.0 cm (WxDxH)
Weight295 g
Package Content
Router (XD4R)
Node (XD4N)
RJ45
Adapter
QSG
Warranty Card
Operation modeWireless router mode
Access point mode
Note
*Router(XD4R):1x Gigabit WAN/LAN port;1x Gigabit LAN Port; Weight: 295g; Wireless router mode.mesh mode.Access point mode
*Node(XD4N):1x Gigabit LAN Port; Weight: 290g; mesh mode
*Content may vary in different regions.
